This page provides specifications of knee specimen OKS007. This is a (likely healthy) elderly male specimen candidate.

Specimen Characteristics

Right knee

Gender: Male

Age: 71 years

Race: White

Height: 1.7 m

Weight: 65.77 Kg

BMI: 22.7

Serologically tested: Yes.

X-ray:

Experimentation Workflow

Experimentation

-- aerdemir 2015-02-02 14:18:21 All, please complete relevant sections of this page during and after experimentation.

Specimen

Reference Specification: Specifications/Specimens - Revision as of February 1, 2015

Leading Team Member: Snehal Chokhandre

Supporting Team Members: Ahmet Erdemir

Timeline: February 1, 2015 @ ~ 9:30 AM (specimen pulled out of freezer)

Data Location:

Protocol Deviations:

  1. None.

Notes:

  1. None.

Specimen Preparation

Reference Specification: Specifications/SpecimenPreparation - Revision as of February 2, 2015

Leading Team Member: Tara Bonner

Supporting Team Members: Snehal Chokhandre, Craig Bennetts

Timeline:

Data Location:

Protocol Deviations:

  1. None.

Notes:

  1. Dissected and keeping skin-fat-muscle layers from thigh and shank.
  2. The tibia Optotrak plug was oriented in an oblique manner (with two screws on the anterior side pointing superiorly).
  3. The femur registration markers were placed to medial, lateral, and posterior sides (alternative configuration).
  4. Suture needs to be ordered for upcoming specimens.
  5. Dissected and keeping the femoral head.
  6. Dissected and keeping bone from femoral and tibial shafts.

Joint Imaging

Specimen Preparation

Reference Specification: Specifications/SpecimenPreparation - Revision as of February 2, 2015

Leading Team Member: Craig Bennetts

Supporting Team Members: Snehal Chokhandre

Timeline: ~2:00 PM - 2:30 PM February 2, 2015 (patella registration marker will be placed next day)

Data Location:

Protocol Deviations:

  1. None.

Notes:

  1. None.

Imaging

Reference Specification: Specifications/ExperimentationAnatomicalImaging - Revision as of February 3, 2015

Leading Team Member: Craig Bennetts

Supporting Team Members: Snehal Chokhandre, Ahmet Erdemir

Timeline:

Data Location:

Data was received from the imaging facilities and uploaded to in-house data management server (http://cobicore.lerner.ccf.org/midas; only accessible within Cleveland Clinic network). Raw DICOM files were stored in the folder Open Knee(s) --> Private --> oks007 --> MRI --> DICOM

DICOM files were converted to NIfTI files, stored in the folder Open Knee(s) --> Private --> oks007 --> MRI --> NIFTI of the in-house data management server. NIfTI files were also disseminated to the public in the 'Downloads' section of the project website, https://simtk.org/home/openknee, under the package oks007.

Data storage and dissemination were accomplished based on the updated imaging specifications, see Revision as of April 22, 2015.

Protocol Deviations:

  1. None.

Notes:

  1. General purpose imaging
    • oks007 General Purpose Imaging

  2. Cartilage imaging
    • oks007 Cartilage Imaging

  3. Connective-tissue imaging
    • oks007 Connective Tissue Imaging

Joint Mechanics

Equipment Preparation

Reference Specification: Specifications/PressureCalibration - Revision as of February 3, 2015

Leading Team Member: Robb Colbrunn

Supporting Team Members: Callan Gillespie

Timeline: ~10:00 AM - ~12:00 PM February 3, 2015

Data Location:

Protocol Deviations:

  1. None.

Notes:

  1. Versions of software used during testing
    1. simVITRO 1.0.3.12
    2. simVITRO Knee Module 1.0.5.10 - with an exception that the bug introduced in this version with regards to femur CS optimization was manually fixed in the code so that it performed in similar manner to previous and future versions.
    3. SSCAD Toolkit 1.0.3.18
    4. SSCAD Toolkit Extensions 1.0.1.3
    5. SSCAD NDI Optotrak 1.0.0.8
    6. NDI Optotrak Drivers 1.0.0.6
    7. BioRobotics Software Configuration 1.0.1.5

    8. BioRobotics Common Tools 1.0.6.3

Specimen Preparation

Reference Specification: Specifications/SpecimenPreparation - Revision as of February 3, 2015

Leading Team Member: Tara Bonner

Supporting Team Members: Robb Colbrunn, Callan Gillespie

Timeline:

Data Location:

Protocol Deviations:

  1. None.

Notes:

  1. None.

Testing

Reference Specification: Specifications/ExperimentationJointMechanics - Revision as of February 3, 2015

Leading Team Member: Tara Bonner

Supporting Team Members:

Timeline:

Data Location:

Data was received from the robotics testing facility and uploaded to in-house data management server (http://cobicore.lerner.ccf.org/midas; only accessible within Cleveland Clinic network). Zipped folders were stored in the folder Open Knee(s) --> Private --> oks007 --> JointMechanics under relevant joint related folders.

Zipped folders were extracted and organized in the dissemination folder under Open Knee(s) --> Private --> oks007 --> JointMechanics --> DISSEMINATION of the in-house data management server. DISSEMINATION folder was downloaded and disseminated to the public in the 'Downloads' section of the project website, https://simtk.org/home/openknee, under the package oks007.

Data storage and dissemination were accomplished based on the updated joint mechanics testing specifications, see Revision as of October 21, 2015.

Protocol Deviations:

  1. None.

Notes:

  1. During tibiofemoral joint testing, 1 Nm internal rotation torque (IE laxity testing at 30 & 90 degrees flexion -- possibly others too) was not captured properly. The IE torque was at 0.5 Nm and off-axis loads (varus) were not minimized to zero. Other levels of loads were fine. A separate trajectory was ran with 1 Nm internal rotation torque starting at 90 degrees flexion down to 0 degrees flexion.

  2. During patellofemoral joint testing at 0 degrees flexion the sensor did not register much pressure and the location of the pressure sensor needed to be readjusted after the test to accommodate higher flexion angles.
  3. During patellofemoral joint testing during 30 degrees flexion there was a discontinuity in pressure measurements on the medial side. This may be attributed to sensor wrinkling or cartilage degradation at that area (needs to be checked).
  4. During patellofemoral joint testing at 60 degrees flexion, 600 N loading was repeated as the clamp cover hose was suspected to catch the fixture edge.

Tissue Mechanics

Specimen Preparation

Reference Specification: Specifications/SpecimenPreparation - Revision as of February 3, 2015

Leading Team Member: Snehal Chokhandre

Supporting Team Members: Craig Bennetts, Ahmet Erdemir

Timeline:

Data Location:

Protocol Deviations:

  1. The team decided to postpone the cartilage dissection to the following day. As a result, bone and cartilage were kept in the fridge another night for dissection in the following morning. All ligament, tendon, menisci segments and secondary tissues were dissected and frozen.

Notes:

  1. Fat bursa and transverse ligament were obtained as secondary tissues.

Testing

Reference Specification:

Leading Team Member:

Supporting Team Members:

Timeline:

Data Location:

Protocol Deviations:

  1. None.

Notes:

  1. None.

Data Analysis

Pictured below are the Anterior Posterior laxity graph, the IR/ER laxity graph, and the Varus/Valgus laxity graph.


Modeling & Simulation
